LIGENTEC is a B2B company manufacturing Photonic Integrated Circuits (PIC) for customers in high-tech areas such as communication on ground and space, Quantum technologies, LiDAR and Biosensors. LIGENTEC commercialises the all-nitride-core technology. With the all-nitride-core technology LIGENTEC enables the customers to develop their products in the industrial revolution 4.0.
FABRICATION MODULES
SELECTED PDK COMPONENTS

X2. Multi level photonics circuits

LoCA. Local cladding open for sensing and bonding

M1. High efficiency heater module for thermo-optic tuning

ExSpot. Spot size converters for mode matching to SMF in 1550nm

RIB. Enabling low loss grating coupler and polarisation management

Low loss delay line

Mach-Zehnder Interferometer

Phase shifter

Tunable Mach-Zehnder

Tunable ring resonator

Polarisation management

Splitter
